BakeryLubrication Guide

From the humid proofer to the oven and the spiral freezer, a bakery asks its lubricants to cover an extreme range in a single shift. Lubri-Loy's Engineered Class chain fluids are formulated zone by zone – a tacky proofer chain oil for extreme humidity, synthetic oven chain lubricants for 500°F–600°F service (and White Graphite to 1200°F), and a PAO spiral-freezer fluid rated -40°F to 300°F – backed by NSF H1 greases, silicone release agents and H1 gear, hydraulic and air line oils.

Request a free plant surveyRequest the full guide (PDF)

More Go. Less Gas. · Fighting friction since 1949

What your bakery lubricants are up against

HUMIDITY

Proofer chains run in extreme humidity – the catalog's proofer chain oil is formulated for exactly that environment.

HEAT

Oven chains generally run 500°F–600°F; the White Graphite fluid extends lubrication intervals to 1200°F.

COLD

Spiral freezer chain and conveyors need a fluid that works from -40°F.

RELEASE

Pans and slides need clean release – water-based bulk silicone and an H1 dry-film aerosol.

01

Key products

Catalog numbers, grades and NSF H1 registration numbers exactly as printed in the Lubri-Loy 2027 Product Catalog.

BULK17704055 gal.

Engineered Class Proofer Chain Oil

Food Grade, H1 · Extra Tacky
FOOD GRADENSF H1 · PENDINGTACKY

Meets NSF H1 requirements for bakery facilities. Formulated for extreme-humidity environments; a highly tacky proofer chain lubricant.

Catalog no.
17704055 gal.
Grade
ISO 100 COT
NSF H1
H1 reg. pending
BULKSFGHT-2205 gal. · 55 gal.

Engineered Class High Temperature Oven Chain Lubricant

Food Grade, H1, Synthetic Ester
FOOD GRADENSF H1 · PENDINGSYNTHETIC ESTEROVEN

Synthetic ester oven lubricant protecting chain pins/bushings and oven-chain roller bearings. Smoke-free, reduced deposits. Generally 500°F to 600°F. ISO 68, 100, 150, 320 on request.

Catalog no.
SFGHT-220-6405 gal. · SFGHT-22055 gal.
Grade
ISO 220
NSF H1
H1 reg. pending
BULKWGH1-2205 gal. · 55 gal.

Engineered Class White Graphite High Temp Chain Fluid

Food Grade, H1, Synthetic PAG
FOOD GRADENSF H1PAGTO 1200°F

PAG synthetic chain oil with suspended white graphite. Carrier evaporates cleanly after 520°F; the White-Graphite™ film extends lubrication intervals to 1200°F (650°C).

Catalog no.
WGH1-220-6405 gal. · WGH1-22055 gal.
Grade
ISO 220
NSF H1
147163
BULKSCFH1-0325 gal. · 55 gal.

Engineered Class Extreme Low Temperature Chain Fluid

Food Grade, H1, Synthetic PAO
FOOD GRADENSF H1 · PENDINGSYNTHETIC PAOSPIRAL FREEZER

Fully synthetic PAO fluid for spiral freezer chain and conveyor applications. Excellent rust, corrosion and oxidative properties; -40°F to 300°F.

Catalog no.
SCFH1-032-6405 gal. · SCFH1-03255 gal.
Grade
ISO 32
NSF H1
H1 reg. pending
BULK14704055 gal.

Super Silicone Release Agent

Water-Based
SILICONERELEASE

Water-based silicone lubricating agent: non-drying, long-lasting film; colorless, odorless, non-staining, non-corrosive, with non-volatile maximum-release lubricity.

Catalog no.
14704055 gal.
NSF H1
Not stated in catalog
Super Silicone Dry Mist

Super Silicone Dry Mist

Food Grade, H1
FOOD GRADENSF H1

Silicone release agent leaving a lubricating dry film void of residue. Prevents rust; heat stable to +450°F under adverse conditions.

Catalog no.
140149 oz.
NSF H1
138694

Lubri-Syn No. 21, #2

Food Grade, H1, Synthetic
FOOD GRADENSF H1SYNTHETICNLGI 2

NLGI #2 H1 grease, -80°F to 400°F – especially strong at the cold end. For valves and bearings; resists mildew and fungal growth; highly washout resistant.

Catalog no.
LS-2101414 oz. · LS-216405 gal. · LS-21192120 lb.
Grade
NLGI 2
NSF H1
139231
Lubri-Syn Clear, #2

Lubri-Syn Clear, #2

Food Grade, H1, Synthetic Silica Gel
FOOD GRADENSF H1SYNTHETIC

Synthetic H1 grease with a non-melting thickener that will not wash out. Designed for bearings and slides, -35°F to +375°F, with anti-wear additives.

Catalog no.
LS-21014C14 oz. · LS-21640C5 gal. · LS-21192C120 lb.
Grade
NLGI 2
NSF H1
141806
02

Lube point map – equipment by equipment

Starting points only – always confirm viscosity / NLGI grade against your equipment OEM specification. Verify current NSF listings at nsf.org.

Mixers & Dough Handling6 lube points
Lube pointRecommended productCatalog no.GradeNSF H1 reg. no.
Mixer gearboxes & reducersSelect ISO grade per OEMGear Oil – Food Grade H1, SyntheticFood Grade, H1, Synthetic PAO · EPGOSH1-xxx-6405 gal. · GOSH1-xxx55 gal.
xxx = ISO grade		ISO 150 · 220 · 320 · 460 · 680ISO150 143325 · ISO220 143326 · ISO320 143327 · ISO460 143328 · ISO680 not printed
Gearboxes – mineral H1 alternativeSelect ISO grade per OEMGear Oil – Food Grade H1, MineralFood Grade, H1, Mineral · EPGOH1-xxx-6405 gal. · GOH1-xxx55 gal.
xxx = ISO grade		ISO 68 · 150 · 220 · 320 · 460ISO68 not printed · ISO150 142245 · ISO220 140213 · ISO320 142246 · ISO460 142247
Mixer & agitator bearingsLubri-Syn Clear, #2Food Grade, H1, Synthetic Silica GelLS-21014C14 oz. · LS-21640C5 gal. · LS-21192C120 lb.NLGI 2141806
Bowl-lift / hydraulic circuitsSelect ISO grade per OEMHydraulic Fluid – Food Grade H1, MineralFood Grade, H1, Mineral · Anti-WearHFH1-xxx-6405 gal. · HFH1-xxx55 gal.
xxx = ISO grade		ISO 22 · 32 · 46 · 68 · 100ISO22 not printed · ISO32 140105 · ISO46 139414 · ISO68 139413 · ISO100 139412
Seals, O-rings & valve assembliesRemoved by CIP/COP solutionsLubri-Seal Assembly GelFood Grade, H1, Synthetic90044 oz.—139643
Dividers & food-handling equipmentWhite oil lubricant / dust controlTechnical Grade White Mineral OilFood Grade, H1WMO-xxx-6405 gal. · WMO-xxx55 gal.
xxx = ISO grade · totes/bulk: see reference		ISO 15 · 22 · 32 · 46 · 68 · 100ISO15 147162 · ISO22 147210 · ISO32 not printed · ISO46 147211 · ISO68 147212 · ISO100 147209
Proofer3 lube points
Lube pointRecommended productCatalog no.GradeNSF H1 reg. no.
Proofer conveyor chainExtra tacky, extreme humidityEngineered Class Proofer Chain OilFood Grade, H1 · Extra Tacky17704055 gal.ISO 100 COTH1 reg. pending
Proofer bearingsResists mildew & fungal growthLubri-Syn No. 21, #2Food Grade, H1, SyntheticLS-2101414 oz. · LS-216405 gal. · LS-21192120 lb.NLGI 2139231
Spot chain & cable lubricationAerosol to drumExtreme Penetrating Oil, Chain & Cable FluidFood Grade, H1701111 oz.
76415 gal. · 7704155 gal.		—Aerosol 138771
Bulk 139610
Oven5 lube points
Lube pointRecommended productCatalog no.GradeNSF H1 reg. no.
Oven chain pins, bushings & roller bearingsGenerally 500°F–600°FEngineered Class High Temperature Oven Chain LubricantFood Grade, H1, Synthetic EsterSFGHT-220-6405 gal. · SFGHT-22055 gal.ISO 220H1 reg. pending
Extreme-heat chains (to 1200°F)Carrier evaporates cleanly after 520°FEngineered Class White Graphite High Temp Chain FluidFood Grade, H1, Synthetic PAGWGH1-220-6405 gal. · WGH1-22055 gal.ISO 220147163
Oven chains where H2 is acceptableH2 – not for incidental food contactEngineered Class High Temperature Chain Fluid, H2High Temperature Synthetic Ester · H217766405 gal. · 17704655 gal.—H2 – not H1
Oven drive gearboxesSelect ISO grade per OEMGear Oil – Food Grade H1, SyntheticFood Grade, H1, Synthetic PAO · EPGOSH1-xxx-6405 gal. · GOSH1-xxx55 gal.
xxx = ISO grade		ISO 150 · 220 · 320 · 460 · 680ISO150 143325 · ISO220 143326 · ISO320 143327 · ISO460 143328 · ISO680 not printed
Bearings with intermittent high heat-40°F to +350°F; int. to +500°FLubri-Syn ALC, #2Food Grade, H1 · Synthetic Aluminum Complex9014SAC14 oz.NLGI 2147155
Pan Handling & Release3 lube points
Lube pointRecommended productCatalog no.GradeNSF H1 reg. no.
Pan & surface release (bulk)Water-based; NSF status not statedSuper Silicone Release AgentWater-Based14704055 gal.—Not stated in catalog
Release dry film (aerosol)Heat stable to +450°FSuper Silicone Dry MistFood Grade, H1140149 oz.—138694
Depanner slides & guides (non-metal to metal)Super Silicone Wet MistFood Grade, H1140199 oz.—138878
Cooling & Spiral Freezer3 lube points
Lube pointRecommended productCatalog no.GradeNSF H1 reg. no.
Spiral freezer chain & conveyor-40°F to 300°FEngineered Class Extreme Low Temperature Chain FluidFood Grade, H1, Synthetic PAOSCFH1-032-6405 gal. · SCFH1-03255 gal.ISO 32H1 reg. pending
Cold-zone bearingsDown to -80°FLubri-Syn No. 21, #2Food Grade, H1, SyntheticLS-2101414 oz. · LS-216405 gal. · LS-21192120 lb.NLGI 2139231
Cold-zone spot greasing (aerosol)-40°F to +435°FSynthetic Spray GreaseFood Grade, H1, Synthetic90099 oz.—138909
Slicing, Bagging & Packaging5 lube points
Lube pointRecommended productCatalog no.GradeNSF H1 reg. no.
Packer & wrapper chainsConfirm grade when orderingEngineered Class Packer Chain OilFood Grade, H1 · White Mineral Oil17704355 gal. · 17704255 gal.ISO 320 COT / 460ISO 460: 139411 · ISO 320 COT: reg. pending
Slicer / bagger bearings & slidesLubri-Syn Clear, #2Food Grade, H1, Synthetic Silica GelLS-21014C14 oz. · LS-21640C5 gal. · LS-21192C120 lb.NLGI 2141806
Pneumatic cylinders & FRL lubricators – mineralPremium Air Line Lubricant – Food Grade H1, MineralFood Grade, H1, Mineral17641M5 gal. · 177041M55 gal.—140105
Pneumatic lubricators – synthetic-80°F to +400°FPremium Air Line Lubricant – Food Grade H1, SyntheticFood Grade, H1, Synthetic170321 qt. · 176415 gal. · 17704155 gal.—139230
Conveyor belts (flat, round, V)Synthetic Belt DressingFood Grade, H1, Synthetic801310 oz.—H1 reg. pending
Conveyors & Plant Utilities4 lube points
Lube pointRecommended productCatalog no.GradeNSF H1 reg. no.
Conveyor bearingsImpact-FG, #1 & #2Food Grade, H1, Aluminum Complex901414 oz. · 96405 gal. · 9192120 lb. · 9704055 gal.NLGI 2147230, 141320
Wash-down conveyor bearingsSevere water washoutImpact-FG CSC, #2Food Grade, H1 · Calcium Sulfonate Complex9014CSC14 oz. · 9640CSC5 gal. · 9192CSC120 lb.NLGI 2147161
Air compressors (rotary screw, vane, reciprocating)Select ISO grade per OEMHydraulic Fluid – Food Grade H1, SyntheticFood Grade, H1, Synthetic PAO · Zinc-FreeHFSH1-xxx-6405 gal. · HFSH1-xxx55 gal.
xxx = ISO grade		ISO 32 · 46 · 68ISO32 143321 · ISO46 143322 · ISO68 143323
Fasteners & anti-gallingBrush-topAnti-Seize Stainless Steel PasteFood Grade, H190088 oz.—142269

Request the full guide (PDF)Includes the complete product reference and SKU consolidation worksheet.

03

Why Lubri-Loy

One supply partner for every lubrication need.

NSF H1 registration

Working directly with NSF International, Lubri-Loy ensures its products maintain proper H1/3H registration. NSF H1 lubricants are formulated for incidental food contact – search nsf.org by registration number to verify.

95%

“We offer interchange products for 95% of aerosols, greases and bulk oils – eliminating the need to carry excessive SKUs of similar products.”

Lubri-Loy 2027 Product Catalog

Fewer SKUs, one source

  • Hydraulic Fluid – Food Grade H1, Synthetic – One H1 PAO fluid the catalog lists for rotary screw, vane and reciprocating air compressors, hydraulic systems, pumps, motors, bearings, chains and airline lubricators.
  • Impact-FG, #1 & #2 – The 9014 cartridge is a catalog top seller; the same Impact-FG grease is available as aerosol 9011 and in 5 gal., 120 lb. and 55 gal. packs.
  • Extreme Penetrating Oil, Chain & Cable Fluid – One H1 penetrant that doubles as chain & cable fluid – 11 oz. aerosol, 5 gal. pail and 55 gal. drum.
  • Lubri-Syn ALC, #2 – Synthetic aluminum complex H1 grease the catalog calls "an excellent choice for streamlining SKUs."

Free plant lubrication survey

Let us walk your proofer, oven, freezer and packaging lube points.

Every manufacturing facility is unique. A Lubri-Loy representative will customize a lubrication program based on your needs – eliminating inventory duplication and obsolescence, correcting minimums and maximums, re-establishing reorder points and implementing a single-source managed-inventory concept.

  1. Survey every fluid, fill point and usage rate
  2. Consolidate SKUs with a Lubri-Loy cross-reference
  3. Rack, tag & label – color-coded, H1 separated from non-food grade
  4. Managed inventory – reorder via lubriloy.com or your rep

Your survey checklist

  • Mixers & Dough Handling
  • Proofer
  • Oven
  • Pan Handling & Release
  • Cooling & Spiral Freezer
  • Slicing, Bagging & Packaging
  • Conveyors & Plant Utilities

Prefer to talk? Call 636-561-5007 · lubriloy.com · customercare@lubriloy.com

Request a survey

We’ll contact you to schedule. Or call 636-561-5007.
